Trotec Speedy 100

Trotec Speedy 100
Tool Type: “Laser Cutter”
Location: “Microfluidics lab”
Supervisor Tool Lead
David Bothman Jeran Bruce & Vedad Bassari
(805) 893-4125 (424) 610-6312 & (818) 942-5523
bothman@cnsi.ucsb.edu jrbruce@ucsb.edu & vedad@ucsb.edu
Description: “Bright Light Cutter”
Manufacturer: “Trotec”

About

One of two laser cutters, the Trotec is located in the Innovations Workshop above its fume extractor. Both laser cutters utilize CorelDraw as a 2D sketch manager which is then imported into Trotec's specific cutting software. CorelDraw can be used to create the 2D sketch, however importing a DXF file or PDF into CorelDraw from Solidworks or other CAD packages is preferred due the CAD packages integrated features and functions.


Training Documentation

Detailed Specifications

Work Area: 910 x 305 mm
Max Workpiece Height: 125 mm
Laser Power: 10-120 Watts


Safety Concerns

  • Looking directly into the laser can cause retinal damage.
  • Confirm that the fume collection system is running whenever the laser is cutting or engraving.
  • See list of approved materials for laser cutting, some require nitrogen gas if flammable, or could release chlorine gas if cut.
  • NO NOT CUT NON APPROVED MATERIALS INCLUDING METALS.
  • Laser lenses must be cleaned within ONE WEEK of time of use. If lenses has not been cleaned, clean before use to avoid damaging lenses.
